Cheap 80 Tons 4 Axles Lowboy Trailer

Chengda is a company specializing in the manufacture of lowboy trailer, with many years of experience in lowboy trailer manufacturing, and the quality of lowboy trailers is guaranteed. We can provide you with a variety of lowboy trailer customization services.

Contact Now

Product Details

Product Description:

The main beam of the trailer is made of high-strength steel Q345, which is precisely welded and has the characteristics of high strength and good toughness.

The trailer axle adopts FUWA, a famous heavy-duty axle brand in China. This axle has been tested in the market for many years and is still popular with customers. We also offer other brands of axles for you to choose from. Optional ABS anti-lock braking system can improve safety.

The suspension system can be selected from ordinary suspension system and air suspension. The dead weight of air suspension is low, and the center of gravity of the lowboy trailer can be adjusted.

lowbed trailer overview

Specification

Type	3 Axle Lowbed Semi Trailer
Loading capacity	60ton
Dimensions	13000x3000x1600mm
Main Beam	Height:500mm,Upper plate:16mm, Middle plate:10mm, Bottom plate:18mm, Material:Q345B steel
Platform	3mm diamond plate
Axle	3axles 13T/16T ,FUWA/ BPW/ ZY Brand
Gooseneck	Optional
King pin	JOST brand or Chinese brand 2.0 or 3.5 inch
Landing gear	JOST brand or Chinese brand 28tons
Suspension	Mechanical suspension(Germany or America type) or Air suspension(China brand or BPW brand)
Steel Spring	90(W)mmx13(Thickness)mmx10 layers
Tire	11.00R20 or 12R22.5 12 pieces

The above lowboy trailer specifications and some accessories can be adjusted according to your needs. We will provide you with the best and most economical option according to your actual situation (the country where you are, the goods to be transported, whether the height is limited, road conditions, etc.).

Details

Lowbed trailer details

Lowboy trailer with more specifications

We provide not only multi-axle lowbed trailer and special lowboy trailer, but also container flatbed trailer and tractor heads. You can choose according to your needs, contact us to get preferential price.

Packing & Delivery

--Container Shipping Method:

Use this method, should cut the goose and when container arrive your port, should weld the goose back before.

It can save a lot of freight for you.

--Bulk:

Very normal and popular way to transport low bed semi trailers,price is suitable and the trailer will not cut the goose.

--RO-RO:

Comparing with others, more expensive.

But more secure and stable. No wind, no rain, or sea .Keeping good condition well.
