4 Axle End Dump Trailer

Chengda Group is one of the famous semi-trailer manufacturers in China, our 4 axle end dump trailer is an excellent semi-trailer in our product line, it is designed and manufactured to the highest standards to ensure the safest, most durable, and high-quality performance.

  Contact Now
Product Details

Product Description

4 axle end dump trailer is a common type of semi-trailer, which is widely used in domestic and international markets. This semi-trailer uses state-of-the-art technology and innovative design to meet customers' high quality, safety, and performance demands.

In terms of design, we have fully considered comfort, convenience, and safety. This semi-trailer is equipped with an advanced air suspension system, an anti-overturning system, and an emergency braking system, which can ensure stability and safety during driving. The shape and interior of the vehicle have been optimized to make the vehicle more beautiful and enhance the comfort of use.

In terms of performance, we equip our vehicles with high-quality components and parts, including high-quality steel, high-strength alloy components, and high-volume tires. These designs and the use of materials can ensure the durability and long life of the vehicle.

Specification of 4 axle end dump trailer

Brand

Chengda

Application

Coal/Mine/Stand/Stone Loading

Dump Style

Rear Dump

Loading Capacity

30T-100T

Axle

2/3/4*13/16T
VEHICLE MASTER/FUWA/BPW

Length

11000mm

Width

2500mm

Height

2800mm

Cylinder

HYVA (model is according to the length of cargo box)

Floor Plate Thickness

5mm

Cargo Thickness

4mm

Cargo Style

Rectanglular/Round

Front Axle Lifting

Available

Main Beam

Material Q345/T700

Height: 500mm

Upper Plate: 14mm

Middle Plate: 8mm

Lower Plate: 16mm

Tire

11.00R20/12R222.5*8/12/16 pieces
Linglong/Triangle/Double-Coin/Bridgestone

Rim

8.0/9.0*8/12/16 pieces, steel/aluminum

Suspension

Mechanical/Airbag

Leaf Spring

90mm*13/16mm*10 pieces

Landing Gear

28T two-speed, JOST

King Pin

#50(2")/#90(3.5"), JOST/Other Brand

Tool Box

Steel/aluminum

Why choose us?

1. Technical Strength

Chengda Group has an R&D team with strong technical strength, who have rich experience and deep technical knowledge in the field of semi-trailer manufacturing. Our engineers use the most cutting-edge research results, use the most optimized design scheme, and formulate the most accurate manufacturing methods, making our product quality at the forefront of the industry.

2. Strong production capacity and supply chain management

Our production process is lean and employs the latest modern technology to ensure an efficient and high-quality manufacturing process. This enables us to meet complex and high-volume orders from customers worldwide with guaranteed on-time delivery. In addition, our supply chain management system is very advanced, which can ensure the reliable supply of raw materials for products, thereby minimizing production costs and ensuring high efficiency and flexibility.

3. Perfect after-sales service

Chengda Group insists on providing high-quality after-sales service, and we have established long-term and close cooperative relationships with our customers. We provide customers with fast and professional technical support and ensure that any problems that may arise are solved for customers. During the sales process, we guarantee to provide timely and accurate information, so that customers can know the order status at any time and provide corresponding suggestions and assistance. In our after-sales service, "customer first" is our consistent aim.

4 axle end dump trailer

In Conclusion

Chengda Group's 4 axle end dump trailer adopts advanced technology and the best materials and undergoes a standardized manufacturing process to provide you with excellent performance and the highest safety standards. Our technical strength, production capacity, and after-sales service are our advantages, which are worthy of the choice and trust of our customers. No matter what kind of semi-trailer your business needs, Chengda Group has the ability to provide you with the best solution, you are welcome to contact our sales representatives at any time to learn more about our semi-trailer and service in detail.

4 axle end dump trailer
